Description
SPECIFICHE TECNICHE:
INPUTS
1- Balanced XLR
1- Balanced ¼” TRS
1- Unbalanced RCA
PERFORMANCE
Frequency Response42 Hz – 20 kHz
Crossover Frequency2.5 kHz
LF Amplifier Power75W
HF Amplifier Power65W
Peak SPL (@ 1 meter)104 dB
LF Driver6.5″ reinforced woofer
HF Driver1.25″ silk dome tweeter
Input Impedance10 kO
Dispersion100 degrees horizontal by 60 degrees vertical
USER CONTROLS
Volume RangeA-type taper
MF Control-6, 0, +6 dB
HF Control-6, 0, +6 dB
Low CutFlat, 80 Hz, 100 Hz
Acoustic SpaceFlat, -2 dB, -4 dB
PROTECTION
RF interference
Output-current limiting
Over-temperature
Turn-on/off transient
Subsonic filter
External mains fuse
POWER
100-120V ~50/60 Hz or 220-240V ~50/60 Hz
CABINET
Vinyl-laminated, medium-density fiberboard
PHYSICAL
Width9.4″ (240 mm)
Depth9.5″ (242 mm)
Height14.4″ (365 mm)
Weight18.5 lbs (8.4 kg)
